200G QSFP56 to 4xSFP56 50G Direct Attach Copper（DAC） 0.5~3Meter
- Hot-pluggable QSFP56/SFP Form Factor
- Available in lengths from 0.5 to 3 meters
- Power consumption <0.1W Each End
- 4-lane 53G PAM4 transceiver that supports 200Gbps at QSFP56 end
- 53G PAM4 transceiver that supports 50Gbps at QSFP56 per end
- Case Operating Temperature 0°C to 70°C(32 to 158°F)
- Compliant with QSFP56/SFP MSA,IEEE802.3cd, SFF-8636,SFF-8472
- RoHS-6 compliant and lead-free
- Ethernet, Infiniband, cloud data centers, and high-performance computing networks, applicable for short-distance connections inside cabinets.
Warranty : 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.
| Part Number | Q56200-4SFP50DxxC | Form Factor | QSFP56 to 4xSFP56 |
| Max Data Rate | 212.5Gbps (4x 53.125Gbps) | Cable Length | 0.5~3Meter |
| Cable Type | Passive DAC | Wire AWG | 26~30AWG |
| Jacket Material | PVC/LSZH (OFNR) | Operation Temperature | 0 to 70°C (32 to 158°F) |
| Max. Power Consumption | < 0.1W Each End | DDM/DOM | Supported |
| Protocols | QSFP56/SFP56 MSA,IEEE 802.3cd, SFF-8636,SFF-8472. | ||
