56G QSFP+ to QSFP+ Copper Direct Attach Cable
The 56G QSFP+ to QSFP+ direct attach cable runs on passive copper wire, ensuring connection quality without the need for additional power. The DAC complies with IEEE802.3cd and SFF-8432 standards. Available in various wire gauge options from 30 to 24 AWG, and various cable length options (up to 7m). It is suitable for cost-effective short-distance interconnection in telecom operators or data center computer rooms, and LAN or SAN applications with interconnection speeds up to 50G.
Warranty : 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.
| Product Number | QSFP-56G-PC5M | Vendor Name | Fiberolink |
| Connector | QSFP+ to QSFP+ | Max Data Rate | 56Gbps |
| Cable Length | 5m (16.4ft) | AWG | AWG 26 |
| Jacket Material | PVC(OFNR) | Minimum Bend Radius | 45mm |
| Operation Temperature | 0~ 70 °C (32 to 158°F) | Protocols | 56G InfiniBand / SFF- 8436 |
