32G SFP28 850nm SR
- Supports up to 28.05Gbps bit rates
- Hot-pluggable SFP+ footprint
- 850nm VCSEL laser and PIN photodiode
- Up to 70m for OM3-MMF and 100m for OM4-MMF transmission
- Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
- Compatible with RoHS
- Single +3.3V power supply
- Real-Time Digital Diagnostic Monitoring
- 16GFC/32GFC Fibre channel
Warranty : 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.
| Product Model | SFP28-32G85-SW | Vendor Name | Fiberolink |
| Form Factor | SFP28 | Max Data Rate | 28.05Gbps |
| Wavelength | 850nm | Max Distance | 70m over OM3 / 100m over OM4 |
| Connector | Duplex LC | Transmitter Type | VCSEL 850nm |
| Cable Type | MMF | Receiver Type | PIN |
| TX Power | -8.4~+2.4dBm | Receiver Sensitivity | < -10.0dBm |
| Protocols | MSA Compliant, SFF-8472 | Operation Temperature | 0 to 70°C (32 to 158°F) |
