16G SFP+ 1310nm LR

Up to 14.025Gb/s data links
1310nm DFB laser and PIN receiver
Up to 10km on 9/125um SMF
Hot-pluggable SFP footprint
Support Digital Monitoring interface
Class 1 laser safety certified
Cost effective SFP+ solution, enables higher port densities and greater bandwidth
RoHS-10 compliant and lead-free
Single +3.3V power supply
2-wire interface for management specifications compliant with SFF-8472 digital diagnostic monitoring interface for optical transceivers
All-metal housing for superior EMI performance
Case operating temperature Commercial: 0 ~ +70 oC Extended: -10 ~ +80 oC Industrial: -40 ~ +85 oC

Warranty : 30-Day Free Return, 3-Year Free Replacement, 5-Year Warranty, Lifetime After-sales Technical Support.

Brand	Fiberolink	Optcore Part Number	sfp-16G-1310-10
Form Factor	SFP+	Data Rate	16Gb/s
Wavelength	1310 nm	Fiber Type	SMF
Max Distance	10km	Optical Components	DFB/PIN
Transmitter Power	-5 ~ 2 dBm	Extinction ratio	> 3.5 dB
Receiver Sensitivity	< -12 dBm	Receiver Overload	> 2 dBm
Connector	LC Duplex	Digital Diagnostic Monitoring	Yes
Environment	Operating: 0°C to 70°C Storage: -40°C to 85°C	Weight	0.03 kg
Application	High-speed storage area networks − Switches and hubs − Network interface cards − Mass storage systems − Host bus adapters Tri-Rate 4G/8G/16G Fibre Channel	Compliance	IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS
